Durite's 400 Amp Battery Switch with Removable Key and Lockout Hole
£54.99
Availability: - out of stock
Durite 0-605-53 12 or 24 Volts DC heavy-duty battery isolator with a removable metal key and 8mm lock-out hole.
12V-24VDC battery isolator switch with removable key and splash-proof cover.
Rated 400A at 24VDC (4000A for 5 seconds).
M10 studs.
8mm diameter lock hole to stop tampering.
Requires 24mm hole.
Splash-proof to IP65.
Pack Quantity: 1 piece.
- Part No. - 0-605-56
| Volts 24 VDC Max | |
| Amps 250A Continuous. 2500A Max for 5 Seconds | |
| Type D1 Normally Open | |
| Studs 2 x M10 | |
| Stud Tightening Torque 1.5+/- 0.1 daNm | |
| Contacts Copper | |
| Connections Not Polarized | |
| Protection IP65 | |
| Weight 0.562Kg | |
| Operating Temperature -40C - +85C | |
| Certificate n/a | |
| Dimensions Please see above (dimensions in mm) |
